Qnap TS-869U-RP Ghana

The Qnap TS-869U-RP Ghana features 8-Bay 2U SATA Turbo NAS Server for SMBs. The 8-bay, all-in-one NAS server with exceptional performance provides the storage requirements of modern SMB IT environments. Ensuring secure cross-platform file sharing for Windows, Mac and Linux/UNIX users, an iSCSI / IP-SAN storage combo solution and a number of value-added business applications. Critical business information can be safely protected against unexpected data loss with a set of integrated backup solutions. Qnap TS-869U-RP Ghana is also an ideal shared storage solution for virtualized and clustered environments with VMware Ready and Citrix Ready certification and has a proven compatibility with Microsoft Hyper-V environments.

The Qnap TS-869U-RP Ghana has intuitive MyCloudNAS service that  simplifies the process of publishing content present in the Turbo NAS over the Internet and helps you create a private cloud in just a few simple steps. Mobile apps including Qfile, Qmanager and Qmobile provide iOS or Android users a convenient way to access and monitor the Turbo NAS live and on the go. Moreover, utilize the Surveillance Station Pro on the Qnap TS-869U-RP to manage the connected IP cameras and set up a video surveillance system with comprehensive monitoring, recording and playback features through mobile access.

Key Features

• CPU – Intel® Atom™ 2.13GHz Dual-core Processor
• DRAM – 1GB RAM (Expandable RAM, up to 3GB)
• Flash Memory – 512MB DOM
• Hard Disk Drive – 8 x 3.5” or 2.5” SATA 6Gb/s, SATA 3Gb/s hard drive or SSD
• LAN Port – 2 x Gigabit RJ-45 Ethernet port
• Centralized Storage, Backup, and File Sharing for Business
• NAS, iSCSI/ IP-SAN Storage Combo Solution for Server Virtualization
• Private Cloud Storage for Ease of Deployment
• Exceptional Performance: 221.8 MB/sec Reading, 220.8 MB/sec Writing

Cross-platform Sharing with Antivirus

Qnap TS-869U-RP Ghana supports SMB/CIFS, NFS and AFP protocols for file sharing across Windows, Mac, Linux/UNIX networks. Your accounts and shared folders can be created via a user-friendly web based interface without IT expertise. The integrated antivirus solution for the Turbo NAS ensures business stability. It offers detection against the latest viruses, malware, worms and Trojan horses.

Windows Active Directory

The Windows AD and Lightweight Directory Access Protocol (LDAP) is a directory service feature that enables you to retrieve user accounts from Windows AD or LDAP based directory server to the Turbo NAS. This reduces time and effort in setting up a new account. You can use the same login name and password to access the Turbo NAS.

Dropbox-like file sync across devices

Qnap TS-869U-RP Ghana is equipped with Qsync, allowing it to be safe data center for file synchronization. Every file uploaded to the TS-869U-RP will be made available for all linked devices including computers, laptops and mobile devices. Qsync is especially useful for frequent travelers as it ensures the most up-to-date files are accessible on all linked devices. Qsync provides multiple ways of file synchronization and group file sharing, greatly enhancing the flexibility of team projects and collaboration.

 Private cloud without constraints

Qnap TS-869U-RP Ghana boasts of myQNAPcloud service allowing remote access from anywhere as it is turned into public cloud services. You can easily get access to the Qnap TS-869U-RP, instantly share multimedia contents and check the system status via the Internet whether you are on the bus or in a coffee shop.

Easy IT Management
The Windows ACL (access control list) feature offers sophisticated shared folder permission settings and thus simplifies IT management for businesses with a large number of users. By enabling the Windows ACL, basic permissions and 13 advanced permissions can be set up from the Windows Explorer and synchronized with the permission settings of the Turbo NAS. In addition, the same permissions apply to AFP, FTP, Web File Manager, and Samba when Advanced Folder Permissions are enabled at the same time.

Advanced Folder Permissions
Advanced folder permissions allow users to configure folder/subfolder access to the Turbo NAS. With this feature enabled, users can manage the folder permissions from Microsoft Windows or the web-based management interface of the Turbo NAS easily.

Well-rounded backup solutions

QNAP Netbak Replicator supports real-time and scheduled data backup on Windows including Outlook email archiving. Apple Time Machine is also supported to provide Mac OS X users with an effortless solution to back up data to the Qnap TS-869U-RP. A wide range of third-party backup software such as Acronis True Image and Symantec Backup Exec are also supported.

Disaster recovery solutions

The Qnap TS-869U-RP Ghana guarantee various data recovery options. RTRR (Real-Time Remote Replication) supports real time or scheduled data backup to remote Turbo NAS or FTP servers and synchronizes files to remote folders from local folders with better backup efficiency and reduced backup time. The Qnap TS-869U-RP also supports sync protocol to back up data to remote servers on a scheduled basis. Data can also be backed up to and restored from a range of cloud storage services, including Amazon® S3, ElephantDrive®, Symform®, Dropbox® and Google® Drive.

High security

The Qnap TS-869U-RP provides numerous security options, such as encrypted access, IP blocking, and other protective features. In an open network environment where business data may be exposed in a potential hack.  IT administrators can also control the access rights of each user to different folders, preventing unauthorized access to important files. The Qnap TS-869U-RP is validated with military-grade FIPS 140-2 AES 256-bit encryption, preventing unauthorized users to access data even if the hard drives or entire system were stolen.

Flexible storage expansion options

The Qnap TS-869U-RP supports large storage capacities; fulfilling business needs to store large amounts of data. It also supports comprehensive RAID management, online RAID capacity expansion, and flexible RAID migration to safely store important data therefore reducing the risks of data loss. With reliable data protection, the Qnap TS-869U-RP is perfect for cross-platform data sharing.

24/7 Surveillance Station

The Surveillance Station turns Qnap TS-869U-RP into a professional surveillance solution with the user-friendly management interface, a wide range of compatible IP camera models, and expandable IP camera channel licenses. It also supports real-time monitoring, recording & playback with a wide range of customizable settings, and with the VMobile app on your iOS® or Android™ devices you can manage the monitoring of cameras anytime, anywhere, for total surveillance of your monitored environment.

Access, sync and share on your mobile devices

The Qnap TS-869U-RP is your private cloud storage that virtually enlarges the capacity of your smart mobile devices. Qfile allows you to access, upload, download, manage, and share stored files easily as if you are carrying tons of files in your pocket. The Qfile app for iOS also allows users to browse videos and photos stored on the TS-869 Pro and play on the TV via AirPlay. Qmanager lets you monitor and manage the Qnap TS-869U-RP remotely and efficiently without turning on a PC.

Easy system setup

The Qnap TS-869U-RP provides system installation without using a CD. Simply visit the setup portal start.qnap.com and follow the setup guide to complete the system setup and download the utilities you want. For beginners, featuring an “Auto Setup” option it provide an easy way to set up the server with recommended settings. All settings can be flexibly changed at a later time after the installation.

Flexible & diverse, yet simple

Supporting SATA 6Gb/s and 3Gb/s hard drives and various 3.5”/2.5” hard drives and SSDs, Qnap TS-869U-RP provides users with high flexibility in selecting hard drives. The various inbuilt I/O ports help accommodate different peripherals, including external storage devices and printers. Meanwhile, the TS-869U-RP allows file sharing and storage on different operating systems, such as Windows, Mac, Linux and UNIX. The simplified system setup process and the friendly-designed graphical user interface enable anyone to easily build up a business private cloud even without IT expertise. Qnap TS-869U-RP has flexible and diverse features, but is simple to use.

Install apps on demand to extend NAS functionality

The QNAP App Center provides a wide range of apps developed by QNAP and third-party developers, including tools for backup/sync, business, content management, communications, download, entertainment, and much more. The App Center is a centralized location for installing, managing, and updating apps on demand. In addition, QNAP’s development platform embraces the open-source spirit to enable developers to create their own apps, adding potentially limitless opportunities for the Qnap TS-869U-RP.

Digital entertainment

Qnap TS-869U-RP Ghana supports various ways to play multimedia content. By using DLNA digital devices, such as HDTVs, video game consoles and Hi-Fi systems, you can view photos and play videos, listen to music on the Qnap TS-869U-RP, and even stream Internet radio stations from all over the world. Just insert the DVB-T USB TV tuner into the Qnap TS-869U-RP, and then you can log on to the Digital TV Station web interface to watch or record digital TV shows. What’s more, the Qnap TS-869U-RP supports HDMI connection and HD Station, turning it into an amazing multimedia player for the living room. Qnap TS-869U-RP perfectly combines smart TV and Hi-Fi systems to provide you with the utmost multimedia enjoyment.

Unmatched Performance

Qnap TS-869U-RP Ghana features 8-bay IP SAN/NAS unified storage, for small and medium businesses. Featuring a powerful Intel® Atom™ 2.13GHz Dual Core Processor and 1GB DDR3 RAM (expandable to 3GB), the Qnap TS-869U-RP provides high efficiency for CPU-consuming tasks and serves more concurrent tasks at the same time. Providing exceptional Performance with up to 222 MB/sec Read & 222 MB/sec

Informative LCD display

The Qnap TS-869U-RP Ghana is equipped with an LCD display panel that provides quick system information making system management even easier.

NAS management  　

The Qnap TS-869U-RP provides comprehensive system tools to increase management efficiency

External Drive Encryption

An external drive attached to the Turbo NAS means easy removal. The important data on the drive needs a solution to protect the data against theft. The Turbo NAS now supports encrypting contents in the external drive.

Advanced RAID Management with Hot-swap Design

The Turbo NAS offers RAID 0, 1, 5, 6, 10, single, and JBOD disk configurations. It also supports hot-swap design so that a failed member drive of a RAID configuration (RAID 1 only) can be replaced by hot swapping without turning off the server.

Online RAID Capacity Expansion

The storage capacity of a RAID configuration can be expanded by replacing larger hard drives. All the data will be kept and seamlessly moved to the newly installed hard drives without turning off the server.

Scheduled Power On/Off

The flexible scheduled power on/off feature is provided for IT administrators to manage the up time of the Turbo NAS according to the working hours. The administrator can set the time for automatic system power on, power off or restart on any days of the week.

UPS Support

The Turbo NAS supports USB UPS devices to allow users to store the data in time and avoid critical data loss when power outage occurs during data transfer. Network UPS allows multiple Turbo NAS servers on the same physical network to be protected by a single UPS via receiving UPS notification on abnormal power supply.

Qnap TS-869U-RP Ghana Technical Specification
