Description

Logitech Rally Bar Camera Ghana

Logitech Rally Bar Camera is all-in-one video bar for midsize meeting rooms, with expansion options for larger groups and settings. Equipped with brilliant optics, powerful audio, and adaptive AI-driven performance, it sets a new standard for video collaboration. It’s remarkably simple to use, manage, and deploy at scale, delivering cinema-quality video and audio in a sleek, all-in-one form factor. Plug and play Rally Bar with any PC or Mac, or leverage the built-in compute to run video conferencing applications directly on the device.

Logitech Rally Bar Camera features a multi-element lens assembly, powerful low distortion speakers, and an advanced mic system to create meeting experiences that sound as good as they look. A dedicated AI camera amplifies RightSight auto-framing and delivers insights about room usage directly to the Logitech Sync dashboard. Upgrade your video collaboration with Rally Bar. Deploy Rally Bar at scale in USB or appliance mode, with exceptional flexibility and ease. With Rally Bar, video meetings can be just as natural and productive as face-to-face collaboration.

Logitech Rally Bar Kumasi

Key Features

Resolutions up to 4K

AI Viewfinder for persistent room view and people count. With a 4K Ultra HD sensor, the Logitech Rally Bar Camera delivers outstanding video quality, exceptional color, and optical precision unlike any other camera. In addition, Logitech can Motorized pan and tilt with RightSight auto-framing technology. Also, Logitech Rally Bar Mini boasts of Right-Sense, a suite of technologies that delivers a better automated user experience.

RightSense Technologies

The Logitech Rally Bar Camera packs suites of advance features. The RightSight detects meeting participants, automatically moves the lens and adjusts the zoom so no one is left out of the picture. Also equipped is RightLight that Intelligently adjusts video settings in all light conditions so everyone always looks their best. RightSound is also another AI-driven voice leveling and unwanted noise suppression deliver outstanding clarity

USB Plug and Play
Plug and play Logitech Rally Bar Camera with any PC or Mac, or leverage the built-in compute to run video conferencing applications directly on the device. You can optionally deploy with Tap to quickly and easily initiate meetings across Zoom, Microsoft Teams, and other cloud services. Easily connects to virtually any PC or Mac®, with no additional software required.

Appliance Mode

Built-in compute allows you to run supported video conferencing applications such as Zoom directly on the device

All-in-One Design

Logitech Rally Bar Camera is a sleek, minimal footprint expedites setup and reduces clutter. Simple to Setup USB ModeConnect via USB to virtually any PC or Mac with no additional software needed

Streamlined, Flexible Installs

Confidently deploy at scale with smart cable management and multiple mounting options. Ensure clean, confident installs with secure cable retention and minimal cabling Mounting Options. Also, take advantage of multiple mounting options to deploy Rally Bar quickly and easily across all your midsize rooms

Adaptive beamforming mic array

Logitech Rally Bar Camera has beamforming mics pick up voices at every seat and focus on the active talker while suppressing ambient noise. Sounds Awesome Rally Bar’s advanced audio engineering delivers powerful, room-filling sound and makes sure every voice is clearly heard. Enjoy great Conversation with Sound Optimization that automatically regulates loud and soft voices while suppressing unwanted noise with AI-based RightSound technology that improves over time.

Expansive room coverage

Logitech Rally Bar Camera boasts of motorized lens that covers rooms 130 degrees across by 80 degrees high, with lossless image quality. Equipped with RightSight lens the Rally Bar camera automatically adjusts so that no is left uncovered

Framed to perfection

Logitech Rally Bar Camera has second built-in camera lens has the ability to detect meeting participants, amplifying RightSight auto-framing. The RightSight detects meeting participants, automatically moves the lens and adjusts the zoom so no one is left out of the picture

Simple to Manage

Monitor the conference room devices from a single platform with Logitech Sync and receive information on room usage with Logitech Rally Bar Camera. Logitech Sync simplifies the large scale provision of video conference devices while reducing on-site visits and support tickets to a minimum via a central, browser-based user interface. This new approach for remote monitoring and device administration simplifies tasks such as firmware updates and activating functions.

Deploy Updates at Scale
Easily propagate upgrades and bug fixes to Logitech Rally Bar Camera and your other supported Logitech devices

Forward-Looking Architecture
Logitech Rally Bar Camera has Sync API is a robust foundation for new insights and integrations

Expansion Ready
Logitech Rally Bar Camera has up to three Rally mic pods for even greater coverage in larger settings

Logitech Rally Video Bar Accra

Logitech Rally Bar Specifications

Camera

Resolution: 4K, 1440p, 1080p, 900p, 720p, and SD at 30fps
Pan: Motorized ±25°
Tilt: Motorized ±15°
Zoom: 15X HD zoom (5X optical, 3X digital available with upcoming software update)
Diagonal field of view (dFoV): 90°
Horizontal Field of View: 82.1°
Vertical Field of View: 52.2°
Total Room Coverage: 132.1° Horizontal x 82.2° Vertical

Speakers

Drivers: 2x 70 mm / 2.7 in
Output: 90dB SPL @1W, 99dB SPL @8.0W, both +/-2dB at ½ meter
Sensitivity: 90+/-3dB SPL at 1W, ½ meter
THD: 1kHz < 2%
Speaker Sampling Rate: 48 kHz

Microphones

Frequency response: 90Hz – 16kHz
Sensitivity: >-36dBFS +/-1 dB @ 1Pa
Microphone data rate output: 48 kHz
Pickup Range: 15 ft / 4.5 m
Beamforming Elements: Six omnidirectional digital MEMS microphones forming five adaptive acoustic broadside beams
Audio processing: AEC (Acoustic Echo Cancellation), VAD (Voice Activity Detector)
Noise suppression: AI filter
Add-on Mics: Supports up to 3 additional Rally Mic Pods for larger conference rooms

RightSense™ Technologies

RightLight™: Renders natural skin tones for each participant.
RightSight: Maintains persistent room awareness and detects human figures to auto-frame participants.
RightSound: Distinguishes speech from other sounds to auto-level voices while suppressing background noise and echo

Interfaces

HDMI Out: 2
HDMI In: 1
USB 3.0: 3x Type A, 1x Type C
Network: 0.04oz (1 g)0/100/1G Ethernet
WiFi: 802.11a/b/g/n/ac (MIMO)
External Mic Input: Yes (proprietary input supports optional Rally Mic Pod, Rally Mic Pod Hub, and Rally Mic Pod Extension Cable)
Remote Control: Bluetooth® Low Energy

Power & Cables

Power supply: Auto-sensing
Operating Voltage/Power: 100-240V, 19V, 4.74A
Power Supply Dimensions: 5 in (127 mm) x 2.01 in (51 mm) x 1.18 in (30 mm)
DC Cable: 5 ft (1.5 m)
AC Cable: 3.28 gy (1 m)
HDMI 1.4 Cable: 7 ft (2 m)
USB A to USB C 3.0 Cable: 2.2 m/7.2 ft

Environmental

Operating Temperature: 0 to 40°C
Storage Temperature: -40 to 70 °C
Humidity: 10 to 95%
BTU/hr: 57 idle, 64 in meeting

Security

Full Disk Encryption: AES-128
Data Encryption: Symmetric Keys, PKI
Device Identity: Protected by device attestation
Device Access: Authenticated using API
Key Protection: Arm TrustZone, RPMP

Certifications & Compatibility

Certifications: Zoom™ Certified, Certified for Microsoft Teams as a USB device.
Compatibility: Plug and play USB connectivity with virtually any video conferencing application
Appliance mode: Supports compatible video conferencing software in appliance mode (no PC required), including Zoom Rooms Appliances.
Certification pending for Microsoft Teams Rooms on Android and additional video conferencing platforms.

General Specifications

Built-in Components: 6 beamforming microphones, PTZ camera, 2 speakers, AI Viewfinder, cable management & retention system, table stand, Logitech CollabOS platform
Enclosure: All-in-one enclosure with integrated table stand and patented speaker suspension system to eliminate vibration-induced camera shake and audio interference
Device Management: Logitech Sync
Displays Supported: 2
Display Resolution: Up to 4K

Accessories

Mounts: Wall Mount for Video Bars, TV Mount for Video Bars
Audio: Rally Mic Pod, Rally Mic Pod Hub, Rally Mic Pod Mount, Rally Mic Pod Extension Cable
Connectivity: Cable USB 10 Logitech Strong [32.81 ft (10 m), 65.6 ft (25 m), 147.64 ft (45 m)]
Touch Controller: Logitech Tap
