Grandstream GWN7603 Ghana



Grandstream GWN7603 Ghana

The Grandstream GWN7603 Ghana presents a compact yet versatile Wi-Fi access point with four Gigabit ports.

Description

Grandstream GWN7603 Access Point Ghana

The Grandstream GWN7603 Ghana presents a compact yet versatile Wi-Fi access point with four Gigabit ports. Among these ports, two feature PSE capability, offering Power over Ethernet (PoE) along with network connectivity for other devices, while an additional uplink port can receive PoE to power the access point. Covering an extensive area of up to 100 meters, the GWN7603 ensures broad coverage without compromising speed or reliability. Its self-power adaptation feature simplifies installation by automatically detecting PoE/PoE+ and PSE, ensuring seamless operation.

Security is paramount, with features such as anti-hacking secure boot and data/control lockdown through digital signatures, unique security certificates, and random default passwords per device. This ensures protection against unauthorized access and breaches. Supporting over 100 Wi-Fi client devices, the access point effortlessly handles high-density environments. Advanced Quality of Service (QoS) features prioritize low-latency applications, guaranteeing smooth performance for critical tasks.

Elevate your wireless connectivity with the Grandstream GWN7603 Ghana Access Point—a reliable, secure, and high-performance solution tailored to meet your network infrastructure’s evolving needs.

Features

  • 27Gbps aggregate wireless throughput, 1x Gigabit and 3x Gigabit wireline speed
  • Up to 100 meters coverage range
  • Self power adaptation upon auto detection of PoE/PoE+ and PSE
  • Anti-hacking secure boot and critical data/control lockdown via digital signatures, unique security certificate/random default password per device
  • Support up to 100+ Wi-Fi client devices
  • Advanced QoS to ensure real-time performance of low-latency applications

Specifications

Client Devices 100+
Range Up to 100 Meters
Network Interfaces
  • 1 x 10/100/1000M uplink Ethernet port with POE/POE+ 2 x 10/100/1000M Ethernet port with PSE
  • 1 x 10/100/1000M Ethernet port
PoE/PoE+ Supports PoE 802.3af/ 802.3at; PSE max output per port: 12W;Max Consumption: 6.5W (Excluding PoE Output)
2.4G Throughput 300Mbps (2×2:2 MU-MIMO); 400 Mbps with 256-QAM
5G Throughput 867Mbps (2×2:2 MU-MIMO)
6G THROUGHPUT N/A
Wi-Fi Standards IEEE 802.11a/b/g/n/ac (Wave-2)
SSIDs 16 SSIDS total, 8 per radio (2.4Ghz and 5Ghz)
Antennas 2 dual band internal antennas
Wi-Fi and Security Systems WEP, WPA/WPA2-PSK, WPA/WPA2 Enterprise (TKIP/AES); WPA3, anti-hacking secure boot and critical data/control lockdown via digital signatures, unique security certificate and random default password per device
Dimensions 135mm x 115mm x 30mm
Mounting Indoor wall mount

Datasheet Download
