Flyingvoice FIP13G VoIP Phone Ghana

The Flyingvoice FIP13G VoIP Phone is a 4 SIP accounts business IP phone specially designed for office staff who are looking for easy-to-use device. The 2.8” color LCD display of the FIP13G provides detailed call information accompanied by icons to maximize usability. Functions and contacts may be accessed quickly via 4 programmable keys. With FIP13G, users can be alerted to Busy Lamp Field (BLF) instantly. It incorporates dual-port Gigabit Ethernet, PoE and 2.4G Wi-Fi that meet your various needs.

The Flyingvoice FIP13G comes with a built-in USB port which allows you to use Bluetooth headset via Bluetooth USB dongle, or record calls by plug in a USB flash drive. Besides, the FIP13G VoIP Phone supports EHS Headset.This allows the user to multitask while communicating on phone, thus save time while working. It also supports Wi-Fi® Wireless connections from a speed of 2.4GHZ. This enhanced feature offers you unparalleled convenience when it comes to content sharing and audio streaming. Flyingvoice FIP13G VoIP Phone uses security algorithms such as configuration files which utilize AES, SRTP and TLS call encryption to secure your conversations. The Flyingvoice FIP13G VoIP Phone is compatible with SIP – based PBX platforms such as Asterisk, BroadSoft and 3CX.

Key Features

Convenient Design

The Flyingvoice FIP13G VoIP Phone packs Server-Initiated Application (SIP) is incorporated for users to plug and play the phone without the need for configurations. Once the phone is connected to the network and powered on, initialization commences automatically, after which the phone is up and ready for use.

Compatibility

Flexibly connect FlyingVoice FIP13G VoIP Phone to your IP PBX System or direct to a VoIP service provider in order to enjoy seamless conference calls. The Flyingvoice FIP13G VoIP phone is based on SIP v1(RFC2543) and SIP v2 (RFC 3261) and works perfectly with most of the SIP platforms such as Asterisk,3CX, and BroadSoft that currently exist in the market.

Management Platform

The Flyingvoice FIP13G VoIP Phone delivers convenience, reliability and seamless integration through the Flyingvoice Device Management Platform via an installed unified firmware. The platform is also used to troubleshoot and solve some of the common complexities that sometimes come during provisioning, call management, and quality control. It also enhances user experience and adoption, making it easy to consolidate clients under one platform.

Maximum Security & Compatibility

 Make all your conversations secure by using the Flyingvoice FIP13G VoIP Phone which uses security algorithms such as configuration files which utilize AES, SRTP and TLS call encryption. The Flyingvoice FIP13G VoIP Phone is compatible with SIP – based PBX platforms such as Asterisk, BroadSoft and 3CX.

HD Voice Quality

The Flyingvoice FIP13G VoIP Phone offers users distraction-free communication courtesy of the inbuilt industry-leading Acoustic Echo Cancelling Technology that delivers superior High Definition sound quality devoid of extraneous noises. This makes it possible to enjoy fluent phone conversations.

 Conference Guide

 Flyingvoice FIP13G VoIp Phone helps the user to easily set up group calls with a single click of a button. The hi-tech device allows for 3 – way group calls. Its phone book offers you an allowance of a maximum of two thousand (2,000) entries per profile. Simply create a meeting or join one seamlessly using your device.

 Connectivity

 The Flyingvoice FIP13G VoIP Phone supports Wi-Fi® Wireless connections from a speed of 2.4GHZ. This enhanced feature offers you unparalleled convenience when it comes to content sharing and audio streaming.

Easy to Use UI Design

 The FlyingVoice FIP13G VoIP Phone is designed to ease call control on the display by using soft keys for daily functions such as transfer, conference and forwarding. You can also access the corporate directory quickly via the soft keys. The user can use the application keys such as the Phone key, Main menu, Contacts and Recents to navigate through the phone and display a list of options including features, network information, administration and many others.

Highly Flexible

The Flyingvoice FIP13G VoIP Phone pushes versatility to a new high, thanks to its ability to complement already existing fixtures for enhanced web and video conferencing, as well as other communication needs. This makes it easy to integrate seamlessly into any office setup without disorienting earlier structures and work ethic. Furthermore, the device is easy to redeploy as the business grows and needs to transform.

Multiple Installation Options

The FIP13G VoIP Phone is delivered in a modern design with a wonderful appearance with ergonomic details that make it easy to use and operate. Whereas it can be mounted on the wall, the adjustable multi-angle Stand gives users the freedom to work with it on any other surface and at different angles.

Call Features

• Message Waiting Indicator
  • The indicator comes with notification to alert you of a new voicemail message. The audible Message Waiting Indicator hinges on a ‘stutter dial tone’ to notify the user when a message is waiting to be retrieved, whereas a visual Message Waiting Indicator triggers a light or notice on the phone display, ensuring that you never miss out on important phone calls.
• Call Transfer
  • This advanced feature of the Flyingvoice FIP13G VoIP Phone allows the user to relocate an inbound call to another phone or messaging system by using a dedicated call transfer button on the phone, or software that has been configured for use on the Wireless Phone.
• Call Waiting
  • You can hear another incoming call when you are already on an active phone call (beep). With the Flyingvoice FIP13G VoIP Phone, you can also turn off call waiting so that incoming calls are directly sent to voicemail during moments you are active on another Phone call.
• Call Holding
  • You can easily place an active phone call on hold in order to make or pick another incoming call using the premium Flyingvoice FIP13G VoIP Phone.

Technical Specifications

• Audio Features
  • HD voice: HD handset, HD speaker
  • Wideband Codec: G.722, Opus, AMR-WB(Optional),
  • 711WB(Optional)
    • Narrowband Codec: G.711(A/u), iLBC, G.729AB, G.723,
  • 726, AMR-NB(Optional)
    • DTMF: In-band, RFC 2833 and SIP info
    • Full-duplex hands-free speakerphone
    • VAD, CNG, AEC, PLC, AJB, AGC
• Phone Features
  • 4 SIP accounts
  • Call hold, mute, DND, redial, auto-answer
  • One-touch speed dial, hotline, SIP message
  • Call forward, call waiting, call transfer (attended/blind)
  • Paging, intercom, 3-Way conferencing, Dial rule
  • Direct IP call without SIP proxy
  • Set date time manually or automatically
  • IP conflict detection
  • 4 GHz Wi-Fi
  • Up to 4 DSS keys
  • USB port (2.0 compliant) for: Bluetooth headset through BT40, USB call recording
• Directory
  • Phone book (2000 records)
  • Blacklist
  • XML/LDAP remote phonebook
  • Phonebook search/import/export
  • Call history: dialed/received/missed (60 records)
• IP-PBX Features
  • BLF
  • Anonymous call, anonymous call rejection
  • Voice mail, call park, call pickup
  • Message waiting indicator (MWI)
• Feature keys
  • 4 Line keys (touchable)
  • 7 features keys: headset, mute, hands-free speakerphone
  • 4 soft keys (touchable)
  • 5 Navigate Keys
  • Volume /-
• Display and Indicator
  • 8″ 320 x 240px color screen with backlight
  • 16-bit depth color
  • LED for call and message waiting for an indication
  • Dual-color (red/green) illuminated LEDs for line status information
  • Intuitive user interface with icons and soft keys
  • Multilingual user interface
  • Caller ID with name and number
  • Power saving
• Interface
  • 2x RJ45 Ports (Ethernet 10/100/1000 Base-T)
  • Support PoE
  • 1 x RJ9 Handset port
  • 1 x RJ9 Headset port
  • 1 x USB 2.0 port
  • 1 x Power adapter
• Network and Security
  • SIP v1 (RFC2543), v2 (RFC3261)
  • Call server redundancy supported
  • NAT Traversal by STUN
  • Proxy mode and peer-to-peer SIP link mode
  • IP assignment: Static IP and DHCP
  • HTTP/HTTPS web server
  • Time and date synchronization using SNTP
  • SDP (RFC 2327) ，UDP/TCP
  • Mutil-VLAN, DSCP and 802.1p QoS
  • SRTP
  • TLS
  • HTTPS certificate manager
  • AES encryption for the configuration file
  • Digest authentication
  • VPN：PPTP, L2TP, OpenVPN
  • IPv4 /IPv6, Dual-stack IPv4/IPv6
  • RTP/RTCP (RFC 1889, RFC 1890)
  • ARP/RARP (RFC 826/903)
  • 1Q VLAN/802.1p/DSCP
  • SNMPv2
  • LLDP/CDP/DHCP VLAN
• Package Contents
  • Flyingvoice FIP13G IP Phone
  • Handset with handset cord
  • Ethernet cable
  • Stand
  • Quick start guide
  • Power adapter (Optional)
