The Cisco WAP321 Ghana is a Selectable-Band Access Point with Single Point Setup. Cisco WAP321 delivers fast, highly secure wireless connectivity supporting high-speed connections with Gigabit Ethernet LAN interface for demanding applications.

Description

Cisco WAP321 Access Point Ghana

The Cisco WAP321 Ghana is a Selectable-Band Access Point with Single Point Setup. Featuring a sleek, affordable, and easy-to-deploy Cisco WAP321 delivers fast, highly secure wireless connectivity supporting high-speed connections with Gigabit Ethernet LAN interface for demanding applications. This Cisco WiFi Ghana bridges wired LANs together wirelessly, making it easier for small businesses to expand their networks.

Built specifically for small businesses, the Cisco WAP321 Ghana offers selectable-band 802.11n wireless technology to deliver high throughput and extended range throughout your office. Advanced quality-of-service (QoS) features let you prioritize traffic to support bandwidth-sensitive applications. This sophisticated control enables you to take advantage of voice over WLAN (VoWLAN) to place or receive calls over the wireless LAN infrastructure.

Designed for growing organizations, the Cisco WAP321 Access Point offers the ability to smoothly scale your network by bridging wired LANs together wirelessly, to reduce cabling and installation costs. It supports multiple Service Set Identifiers (SSIDs) to enable you to segregate traffic for different departments, users, and communication devices.

For companies that need to provide secure wireless guest access, the Cisco WAP321 Ghana offers captive portal support that lets you create a wireless hotspot with visitor authentication. The Cisco WAP321 Ghana is simple to set up and use, with intuitive wizard-based configuration to get you up and running in minutes. A sleek, compact design with flexible mounting options enables the access point to smoothly blend into any small business environment. Power over Ethernet (PoE) support makes the device easy to install without the need for separate power plugs or expensive new wiring.

To enhance reliability and safeguard sensitive business information data, the Cisco WAP321 Ghana supports WiFi Protected Access (WPA2), encoding all your wireless transmissions with powerful encryption. 802.1X RADIUS authentication helps keep unauthorized users out. Single Point Setup is a controller-less multi-access point deployment technology that allows you to deploy and manage multiple access points in a simple and cost-effective way across your premises.

Features

  • Highly secure, high-speed 802.11n wireless networking delivers enhanced throughput and extended range for bandwidth-intensive applications.
  • Wizard-based setup and configuration enables fast, simple deployment.
  • Single Point Setup controller-less multi-access point deployment and management technology makes configuration simple.
  • Gigabit Ethernet LAN interface provides high-speed connectivity for faster downloads and demanding applications.
  • Selectable-band wireless access lets you switch bands to minimize interference from other office devices and improve performance.
  • Robust security, including WPA2, 802.1X with RADIUS secure authentication, and rogue access point detection, helps protect sensitive business information.
  • Support for PoE enables easy installation without the expense of additional wiring.
  • Workgroup Bridge mode lets you expand your network by wirelessly connecting to a second Ethernet network.
  • Elegant, compact design with internal antennas and versatile mounting kit enables installation on a ceiling, wall, or desktop.
  • Intelligent QoS prioritizes network traffic to keep critical network applications running at top performance.
  • Power-saving sleep mode and port control features help maximize energy efficiency.
  • Highly secure guest access enables safe wireless connectivity for visitors.
  • Support for IPv6 lets you deploy future networking applications and operating systems without costly upgrades.

Specifications

Interfaces 10/100/1000 BASE-T autosensing (RJ45)
Powering Options 802.3af Ethernet Switch, Cisco SB-PWR-INJ-12V-xx power Injector or Local Power Supply (SB-PWR-12V-xx)
Frequency Selectable Band 2.4 GHz or 5 GHz ((not concurrent)
Wireless 802.11n, 3×2 multiple input multiple output (MIMO)
Operating modes Access Point mode, WDS bridging, Client Bridge mode
VLAN support Yes
Number of VLANs 1 management VLAN plus 4 VLANs for SSID
Multiple SSIDs 8
802.1X supplicant Yes
SSID to VLAN mapping Yes
Auto channel selection Yes
Spanning tree Yes
Load balancing Yes
IPv6 Yes
Layer 2 802.1Q-based VLANS, 4 active VLANS plus 1 management VLAN
Access control Yes, management access control list (ACL) plus MAC ACL
Rogue access point detection Yes
Quality of service (QoS) Wi-Fi Multimedia and Traffic Specification (WMM TSPEC)
Maximum AP’s per cluster 8
Active clients per cluster 80
Management protocols Web browser, Simple Network Management Protocol (SNMP) v3, Bonjour
HTTP redirect Yes
Wireless isolation Wireless isolation between clients
Roaming Yes
Wi-Fi Multimedia (WMM) Yes, with unscheduled automatic power save
