Description

Cisco Catalyst9130AXE Access Point Ghana

The Cisco Catalyst9130AXE Ghana, offer beyond the Wi-Fi 6 (802.11ax) standard, this Cisco WiFi Ghana provides integrated security, resiliency, and operational flexibility as well as increased network intelligence ensuring reliable wireless to meet the needs of your branch and campus network deployments. The Cisco Catalyst9130AXE Ghana Access Point comes equipped with high-performance Wi-Fi 6 capabilities and innovations in RF performance, security, and analytics, enable end-to-end digitization and help accelerate the rollout of business services by delivering beyond Wi-Fi. This Cisco WiFi Ghana comes with built-in security in the form of secure boot, runtime defenses, image signing, integrity verification, and hardware authenticity.

Features

• Next-generation Wi-Fi 6 (802.11ax) access points with 4×4 Multiple-Input Multiple-Output (MIMO) and four spatial streams :
  • 8×8 :8 single or dual 4×4 :4 on 5 GHz and downlink/uplink Orthogonal Frequency-Division Multiple Access (OFDMA)
  • 4×4 :4 on 2.4 GHz with multiuser MIMO (MU-MIMO) and downlink/uplink OFDMA
• Cisco DNA ready
• Cisco RF Application-Specific Integrated Circuit (ASIC) with next-generation Cisco CleanAir® and upgradable RF features
• Built-in Bluetooth Low Energy (BLE) radio (Bluetooth 5.0)
• Multigigabit Ethernet (1 Gbps, 2.5 and 5 Gbps)
• Supports up to 500 Wi-Fi devices
• IoT ready (Zigbee, Thread)
• Internal and external antenna options

Resilient

Cisco Catalyst9130AXE Ghana provides increased efficiency and cellular-like determinism with up to 4 times the capacity of 802.11ac access points, even in demanding environments

Secure

 Along with built-in security, and Software-Defined Access (SD-Access) support, Cisco Catalyst9130AXE Ghana deliver standards-compliant, enhanced security on open Wi-Fi

 Intelligent

 With multi-RF support paramount for Internet of Things (IoT) devices and expanded ecosystem partnerships, the Cisco Catalyst 9100 portfolio provides unprecedented visibility from mobile devices on the Cisco network, along with enhanced Cisco DNA Assurance

Wi-Fi 6 (802.11ax)

The IEEE 802.11ax emerging standard, also known as High-Efficiency Wireless (HEW) or Wi-Fi 6, builds on 802.11ac. Cisco Catalyst9130AXE Ghana delivers a better experience in typical environments with more predictable performance for advanced applications such as 4K or 8K video, high-density, high-definition collaboration apps, all-wireless offices, and IoT. Wi-Fi 6 is designed to use both the 2.4-GHz and 5-GHz bands, unlike the 802.11ac standard

Cisco RF ASIC

The Cisco RF Application-Specific Integrated Circuit (ASIC) is a fully integrated Software-Defined Radio (SDR) that can perform advanced RF spectrum analysis and delivers features such as Cisco CleanAir, Wireless Intrusion Prevention System (WIPS), FastLocate, and Dynamic Frequency Selection (DFS) detection.

Uplink/downlink OFDMA

Orthogonal Frequency-Division Multiple Access (OFDMA)-based scheduling splits the bandwidth into smaller frequency allocations called Resource Units (RUs), which can be assigned to individual clients in both the downlink and uplink directions to reduce overhead and latency.

Uplink/downlink MU‑MIMO technology

Cisco Catalyst9130AXE Ghana supports eight spatial streams, Multiuser Multiple Input, Multiple Output (MU-MIMO) enables access points to split spatial streams between client devices to maximize throughput.

BSS coloring

Spatial reuse (also known as Basic Service Set [BSS] coloring) allows the access points and their clients to differentiate between BSSs, thus permitting more simultaneous transmissions.

Target Wake Time

A new power-saving mode called Target Wake Time (TWT) allows the client to stay asleep and to wake up only at prescheduled (target) times to exchange data with the access point. This offers significant energy savings for battery-operated devices, up to three to four times the savings achieved by 802.11n and 802.11ac.

Intelligent Capture

Cisco Catalyst9130AXE Ghana boasts of intelligent Capture probes the network and provides Cisco DNA Center with deep analysis. The software can track more than 240 anomalies and instantaneously review all packets on demand, emulating the onsite network administrator. Intelligent Capture allows for more informed decisions on your wireless networks.

Flexible Radio Assignment (FRA) with tri-radio mode

FRA allows the access points to intelligently determine the operating mode of serving radios based on the RF environment and traffic demands. This Cisco WiFi Ghana can operate in the following modes :

• Dual-radio mode : One 8×8 5 GHz and one 4×4 2.4 GHz. One radio will serve clients on the 5-GHz band, while the other serves clients on the 2.4-GHz band.
• Tri-radio mode :  Dual 4×4 5 GHz and one 4×4 2.4 GHz. With two 4×4 5-GHz and one 4×4 2.4-GHz radios (tri-radio) inside the access point, client device capacity can be increased on demand.

The access point’s default mode is dual radio with 8×8 5 GHz and 4×4 2.4 GHz. It has the ability to split the 8×8 radio into two separate 4×4 5-GHz radios through software, thereby enabling the benefits of FRA while allowing the 2.4-GHz radio to remain active.

Industry first 8×8 external antenna access point with smart antenna connector

The Cisco Catalyst9130AXE Ghana Access Points are the first in the industry to provide an 8×8 radio architecture with external antennas. Additionally, these antennas can be split into a dual 4×4 radio architecture. An intelligent physical antenna connector is included on the 9130AX Series with an external antenna. This connector provides advanced network design flexibility for high-density and large open-area environments such as auditoriums, convention centers, libraries, cafeterias, and arenas/stadiums.

Multigigabit Ethernet support

Multigigabit Ethernet provides uplink speeds of 5 Gbps and 2.5 Gbps, in addition to 100 Mbps and 1 Gbps. All speeds are supported on Category 5e cabling, as well as 10GBASE-T (IEEE 802.3bz) cabling.

Bluetooth 5

Integrated Bluetooth Low Energy (BLE) 5 radio enables location-based use cases such as asset tracking, wayfinding, and analytics.

Container support for applications

Container support enables edge computing capabilities for IoT applications on the host access point.

Apple features

Apple and Cisco have partnered to create an optimal mobile experience for iOS devices on corporate networks based on Cisco technologies. Using new features in Apple iOS, in combination with the latest software and hardware from Cisco, businesses can now more effectively use their network infrastructure to deliver an enhanced user experience across all business applications.
