Aver CAM540 PTZ Camera Ghana

The Aver CAM540 PTZ Camera Ghana is a USB Video Conferencing solution that brings 4K Ultra HD image quality with sharp, accurate color to your video conferences in huddle rooms and medium-sized meeting rooms. The CAM540 packs AVer’s new SmartFrame auto-framing technology to 4K high definition video conferencing. With a wide field of view, the CAM540 is guaranteed to provide an incredible communication experience in your meeting room. Easy to use with plug-and-play operation, it quickly connects to virtually any Windows/Mac/Chromebook desktop or laptop computer via a single USB.

The Aver CAM540 PTZ Camera is equipped with high-quality sensors, multi-lens glass, an 86° angle of view, pan/tilt/16x digital zoom (PTZ), auto framing, auto focus, and backlight compensation. Also equipped is Smart-Frame allowing the camera to capture faces with total clarity at any distance, helping to improve the quality and productivity of distance meetings and distance-learning sessions for all participants. The included IR remote control allows you to adjust pan, tilt, and zoom positions, as well as tweak other settings, at the press of a button. Up to 10 position presets can be stored and then recalled via the remote control. In-depth parameter settings and image adjustments can be made with the PTZapp application (free download available separately) installed on your Windows/Mac computer.

Key Features

• For Huddle Rooms & Medium-Size Rooms
• 4K Ultra HD/30 fps over USB, Mac/Windows
• 86° Field of View, Pan/Tilt/16x HD Zoom
• Auto Framing, Auto Focus, Backlight

4K Ultra HD

The Aver CAM540 PTZ Camera supports a high-end Sony 4K CMOS that allows for 4K video to be captured at 30 frames per second, providing users with an unbelievably lifelike meeting experience. Stream video in 4K or regular HD resolution for a crystal-clear image with accurate colors.

16X Total Zoom

The Aver CAM540 PTZ Camera is built with cutting edge 16X total zoom capability. Bringing an unseen level of clarity to video conferencing, the CAM540 maximizes your team’s collaboration with simple, easy, and efficient video communication.

SmartFrame Technology

The Aver CAM540 PTZ Camera boasts of SmartFrame technology. The SmartFrame app maximizes the viewable field with auto-framing solution that effortlessly puts everyone in your meeting into frame fast and with no hassle. No complex settings or time wasting controls simply click a single button and find the most comfortable distance for your meeting with the SmartFrame. Moreover, SmartFrame technology uses facial detection to automatically frame all participants in the room ensuring everyone is included on the screen, no matter their distance from the lens.

Auto White Balance & 2D noise Reduction

Whether your meeting room has low, bright, natural, or a mixture of lighting conditions, the CAM540’s auto white balance, backlight compensation, and 2D noise reduction technology automatically adjust to optimize light balance in tricky conditions and ensure that all faces are clearly lit.

Pan, Tilt & Zoom Movements

The Aver CAM540 PTZ Camera offers superior auto-focus optics that deliver quiet and smooth pan, tilt, and zoom movement. The 16x zoom captures the smallest details with absolute clarity at every focal length. With; Pan: ±160°, Tilt: +90° (up) -30° (down) and 16x HD zoom

PTZapp Application

The Aver CAM540 PTZ Camera is equipped with PTZapp application, that installs on your computer to allow for in-depth setting of all parameters and camera image adjustments (free download for Windows and Mac computers). Upgrade firmware automatically or manually. It is also, compatible with Skype Plugin for answering and hanging up via remote control

10 Camera Presets

The Aver CAM540 PTZ Camera allows you to customize meetings by storing up to 10 PTZ camera presets via RS232 VISCA or UVC (USB video class). The presets are easily accessed with one touch of the IR remote, saving you time and providing flexibility to swiftly move the focus of the camera to predetermined locations in your conference room.

RS-232 VISCA Integration Capabilities

With advanced integration capabilities built into the CAM540 camera (RS232 cable available separately) and VISCA support, the camera can easily be integrated into a controlled environment allowing users to operate and manage it through an AV control panel.

Elegant Compact Design

The Aver CAM540 PTZ Camera features a new sleek and fluid design for conferencing rooms. Compared to traditional designs, the CAM540 is elegant and compact to save you space. The CAM540 easily fits your modern meeting room and provides an experience that both novices and experts can enjoy in style.

Analytics API for Usage Monitoring

The CAM540 features an Analytics API (Application Program Interface) so businesses and third-party software providers can obtain people-counting data for a better understanding of meeting-space usage.

Aver CAM540 Specifications

• Camera

• • Ultra-crystal clear image Support up to 4K; CMOS Sony 4K
  • Frame rate: 4K 30fps, 1080p, 720p, 640×480, 320×240 at 60, 30, 15fps
  • SmartFrame: Automatic FOV adjustment to fit all participants
  • 16X Zoom (4X optical zoom + 4X digital zoom)
  • Auto focus: minimum working distance 1 meter
  • 86° Wide field of view
  • Back light compensation and 2D noise reduction technology for optimizing light balance in different conditions
  • Standard tripod screw holes
  • Analytics API: Enterprises and third-party software providers can obtain people-counting data for better understanding of meeting-space usage

• Motorized Pan and Tilt Movement

• • Pan: ±160°
  • Tilt: +90° (up) -30° (down)
  • 10 camera presets (through remote control)
  • Quiet and smooth pan and Tilt movement

• Connectivity

• • 12V power adaptor
  • Mini DIN6 for RS232 connection
  • USB Type C connector

• Video format

• • YUV, MJPEG

• USB

• • 2.0, 3.1 Gen1
  • UVC (USB Video Class) 1.1

• Control

• • IR remote control
  • VISCA/pelco P/pelco D via RS232
  • UVC/ plug-and play
  • PTZapp

• Security and mount

• • Camera mount included for wall or ceiling
  • Kensington slot

• System requirement*

• • Windows 7/8/8.1/10
  • Mac OS X 10.7 or higher
  • Google Chromebook version 29.0.1547.70, Platform 4319.79.0

• Hardware Spec*

• • 2.4GHz Intel^® Core 2 Duo processor
  • 2GB RAM or more
  • USB 3.1 Gen1 port

• PTZapp application

• • Compatible with SkypeTM Plugin for answering and hanging up via remote control
  • Upgrade firmware automatically or manually
  • Control camera
  • Set parameters and adjust camera ima
  • Diagnose operating status
  • View live video
  • Free download on Windows^® and Mac^® computer

• Power supply

• • AC 100V ~240V, 50/60Hz, 3 meters
  • Consumption: 12V, 2A

• Environmental data

• • Operation temperature: 0 ~40°C
  • Operation humidity: 20% ~80%
  • Storage temperature: -20 ~60°C
  • Storage humidity: 20% ~80%

• Dimension

• • Package dimensions: 227*189*261mm
  • Package weight: 2.54 kg
  • Camera: 97.8 x 130.7 x 171.1 mm/1.5kg
  • Remote control: 200 x 50 x 21 mm/0.09kg

• Package contents

• • Camera
  • Remote control
  • Power adapter
  • USB3.1 Type-C to type-A (6ft)
  • USB3.1 type-A to Type-C adapter
  • Quick-start guide
  • Metal mount, tripod screw
  • Battery

• Optional accessories

• • Mini DIN6 to RS232 adapter
  • 16ft USB 2.0 cable

• Warranty**

• • Camera: 3+2 year
  • Accessories: 1 year

• Compatible Applications

• • Adobe Connect, Blue Jeans, CyberLink U Meeting^®, Cisco WebEx^®, Google Hangout, GoToMeeting™, Intel^® Unite™, Microsoft^® Lync™, Skype™,Skype for Business, V-Cube, vMix, WebRTC, Wirecast, XSplit, ZOOM
